PCBA Manufacturing Services
At our PCBA facility in Shenzhen,we specialize in comprehensive services that cover component sourcing, precision SMT, DIP, cable soldering and functional test.
High precision SMT
2 sided SMT&THT assembly
24-hour rapid delivery
8 million SMT points per day
Soldering 500K plug-in points/day
Conformal coating
IC programming
Functional testing
X-Ray Inspection for BGA Assembly
AOI inspection for SMT
|
Items |
Conventional process |
Unconventional processes |
||
|---|---|---|---|---|
|
PCB specifications for SMT |
Length * Width |
Maximum |
L≤460mm |
L＞460mm |
|
W≤400mm |
W＞400mm |
|||
|
Minimality |
L≥50mm |
L＜50mm |
||
|
W≥30mm |
W＜30mm |
|||
|
Thickness |
Thickest |
4.5mm |
＞4.5mm |
|
|
The thinnest |
0.5mm |
＜0.5mm |
||
|
Components for SMT |
Dimensions |
Component thickness |
≤6.5mm |
6.5mm＜T≤15mm |
|
Maximum size |
200*125mm |
＞200*125mm |
||
|
Minimum specs |
0201 |
01005 |
||
|
0.6*0.3mm |
0.3*0.2mm |
|||
|
QFP, SOP, SOJ and other multi-pin components |
Minimum PIN spacing |
0.4mm |
0.3≤Pitch＜0.4mm |
|
|
CSP、BGA |
Minimum ball spacing |
0.5mm |
0.3≤Pitch＜0.5mm |
|
